Product Features Compliant with IEEE Std 802.3ba, 100G BASE SR4 Ethernet Compliant with QSFP28 MSA Management interface specifications per SFF-8636 Single MPO connector receptacle 4 channels 850nm VCSEL array 4 channels PIN photo detector array Up to 103.1Gb/s data rates Single +3.3V power supply Class 1 laser safety certified Commercial operating temperature:0oC to +70oC [...]
Product Features Compliant with IEEE Std 802.3ba, 100G Ethernet LR4 Compliant with QSFP28 MSA 4 cooled 25Gb/s channels LAN WDM DFB TOSA 4 channels PIN photo detector Single +3.3V power supply Class 1 laser safety certified Power consumption less than 3.5W Commercial operating temperature: -5oC to +70oC Up to 10km on SMF RoHS 6/6 [...]
SOT-S22-10G-80KM Product Features Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector DWDM-rated EML Transmitter Up to 10.3Gb/s bi-directional data links 100GHz ITU Grid, C-Band Single +3.3V power supply Class 1 laser safety certified Commercial operating temperature:0℃ to +70℃ Up [...]
SOT-S22-10G-40KM Product Features Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector DWDM-rated EML Transmitter Up to 10.3Gb/s bi-directional data links 100GHz ITU Grid, C-Band Single +3.3V power supply Class 1 laser safety certified Commercial operating temperature:0℃ to +70℃ Up [...]
SOT-S21-10G-80KM Product Features Compliant with IEEE Std 802.3-2005 10G Ethernet 10GBase-ZR/ZW Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector Cooled EML Laser Up to 10.3Gb/s bi-directional data links Single +3.3V power supply Class 1 laser safety certified Commercial operating [...]
SOT-S21-10G-40KM Product Features Compliant with IEEE Std 802.3-2005 10G Ethernet 10GBase-ER/EW Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector Cooled EML Laser Up to 10.3Gb/s bi-directional data links Single +3.3V power supply Class 1 laser safety certified Commercial operating [...]
SOT-S20-10G-10KM-1310nm Product Features Compliant with IEEE Std 802.3-2005 10G Ethernet 10GBase-LR/LW Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector Uncooled 1310nm DFB Laser Up to 10.3Gb/s bi-directional data links Single +3.3V power supply Class 1 laser safety certified Operating [...]
SOT-S20-10G-300M-850nm Product Features Compliant with IEEE Std 802.3-2005 10G Ethernet 10GBase-SR Electrical interface specifications per SFF-8431 Management interface specifications per SFF-8431 and SFF-8472 SFP+ MSA package with duplex LC connector Uncooled 850nm VCSEL Laser Up to 10.3Gb/s bi-directional data links Single +3.3V power supply Class 1 laser safety certified Operating [...]
1.1 The product overview 1550EH Series external modulation laser transmitter product is a new type of high-performance 1550nm external modulation optical transmitter. Transmitter is the 1U height, and can be easily installed in 19 "rack. 1550EH transmitter is the 1550nm dual-wavelength 7~12dBm optical output, the output signal spectral lines is narrow, more advantages in [...]
The product overview 1.1 The product overview 1310DT Optical Transmitter products adopt the high linearity, optical isolation, the DFB, thermoelectric cooling DFB laser produced by ORTEL 、AOI、Fujitsu、Mitsubishi and other world-renowned semiconductor companies. It can provide high-quality images, digital or compressed digital signal long-distance transmission for cable television and telephone communications. Built-in RF driver amplifier [...]
